9. Programmable Features

9 Programm able FeaturesFeatures Summary

9.1 Programming

1 {MENU}

2 Press {#} and the 3-digit code (page 49 to page

58).

3 Press the desired selection to display the desired

setting.

L This step may be slightly different depending on

the feature.

4 {SET}

5 Press {MENU} to exit.

To select features using the web browser (KX-

MB781, LAN connection only)

You can change features using the web browser instead

of the unit.

1. Start Multi-Function Station. i [Utilities] i

[Configuration Web Page]

L You can also access the unit by entering its IP

address on the web browser.

2. Select the desired category from the menu bar.

[Device Configuration]: features of the unit

[Network Configuration]: features of the network

3. Type “root” as the user name, then enter the

password (feature #155 on page 50). i [OK]

4. Select the desired feature tab at the top of the right

frame.

5. Change the settings or edit information.

L This step may be slightly different depending on

the feature.

6. [Submit]

L The new data will be transferred to the unit.

7. Close the web browser.

Note:

L The settings displayed in the web browser will be

updated by clicking [Reload].

{SET}

{MENU}
