Internet Communication Features

Inbound Routing

Using the Inbound Routing feature, the DX-1000 can route documents received from a G3 fax machine to

email address(s) or to Internet Fax machine(s) connected to a LAN as an email, as well as to other G3 fax

machine(s) over the telephone line.

When an incoming Internet Fax, email or a regular fax document is received, the DX-1000, checks for the

following:

1. First, the DX-1000 checks whether a sub-address is included. If it is, it will look for a sub-address match

within its auto dialer and will route the documents to the corresponding stations email address(s) or

telephone number(s).

2. If no sub-address is specified, then the DX-1000 tries to match the originating fax machine’s Numeric ID

(TSI) with the TSI routing within its auto dialer and will route the documents to the corresponding stations

email address(s) or telephone number(s).

LAN

Internet Fax

DX-1000

G3 Fax

Fax Reception

Transfer to

a G3 Fax

Internet Fax

DX-1000

1. If the originating fax machine does not support the above sub-address function, sub-address destination(s)

cannot be selected.

2. The DX-1000 can not perform routing to mixed address locations (email address(s) and telephone

number(s)) within the same operation.

01005000001

01005020003

01005050003

01005050004

01005050005

Note:

01005070001

01005070002
